AEGIS 200 Watt Multi-Function Programmable Controller with Siren Amplifier & Public Address System

AEGIS 200 is our latest "All-In-One" Programmable Smart Controller for all your Lights, Siren and Public Address functions featuring up to 200 watts of high powered super loud audible tones. AEGIS 200 can support 1 or 2 individual 100 watt speakers with a dynamic microphone for maximum clarity.

• Fully programmable and customizable configuration with PC software:
  • Button & Input style: Maintained, Momentary, Timer and etc.
  • Button Interlink, Interlock & Output port.
  • Tone selection: Primary, Override, Mixer, Hand-free Tone.
  • Multi-press function.
• 15-Button Hand-held Controller w/ built-in Mic, Button buzzer, 6-Traffic Arrow indicator LEDs and power magnet mounting mechanism.
• 12 Outputs (3x 15A, 3x 1 DA, 2x 2A, 4x 0.25A) and 1 dry contact relay output.
• 4 Positive or negative activated Logic Inputs and 1 voltage-variable Analogue Input.
• 12-24VDC multi-voltage Class D amplifier for low amp draw and clean sound.
• 200W amplifier supports one or two 100W speakers (11Ω).
• Separate backlight control and covert mode (backlight disabled).
• Selectable tone including Wail, Yelp, Phaser (Piercer), Hi-Lo, Mechanical, European Tone, etc.
• Heavy-duty power and output connectors with easily accessible fuses.
• Radio Re-Broadcasting (RRB) for audio replay.
• "Record-n-Play" function: Record instant replayable messages up to 20 seconds.
• "MIX TONE" function allows each speaker for a Multi-Speaker Effect.
• Voltage detection, programmable for auto low voltage protection.

Technical Specifications

Input Voltage: 12-24VDC
Standby Current: 0 mA (w/o IGN wire) / <0.35A (w/ IGN wire)
Max. Current:

• 20A@12VDC /10A@24VDC (Siren functions only)
• 100A@12VDC / 50A@24VDC (w/ light outputs)

Siren Output Power: 200W (100W per Speaker) 11Ω
Light Controls:

• 3x 15A
• 3x 10A
• 2x 2A
• 4x 0.25A

AEGIS Product Dimensions

Control Remote Head: 134(L) x 67(W) x 27(H)mm
Relay Control Box: 217(L) x 190(W) x 46(H)mm
