SPARK 10 L.E.D. Amber Beacon Flashing & Rotating​ Light "SAE CLASS 1"

SPARK 10 L.E.D. Beacon, available in AMBER colour also commonly known as Yellow and Orange, feature our latest micro optic reflector design housed internally offering a proper 360 degree high intensity light with a larger profile size for greater visibility. With superior daytime performance when comparing to other beacons, the SPARK Series beacons feature 100% solid state design with no moving parts or globe replacements required. Users can easily select flashing, rotating or combination patterns at different speed levels for each unique application.

Technical Specifications

• SAE J845 Class 1
• ECE R65 Class 2
• MAX 5A @ 12VDC
• 10 Long Life Colour Rich L.E.D.s
• Superior Day Time Clarity & Performance
• Visibly Larger Illuminated Signal Profile
• 10-30VDC Multi Voltage Suitable
• User Selectable Flashing & Rotating Patterns
• Exclusive Micro Reflector Optics Design
• UV Stabilised PC Lens
• IP67 Weather Resistant
• 100% Solid State Technology
• No Replacement Globes or Gears Required
• 3 Bolt Fixed Mount
• Dimensions 80(Height) x 165 Base & 130 Lens(Diameter) mm

Wiring Diagram

• Black = Ground Negative
• Red = +10-30V Positive On/Off
• Yellow = Pattern Select on Momentary Red
