DISCONTINUED - SPARK 10 L.E.D. Amber Beacon Flashing & Rotating​ Light "SAE CLASS 1"




SPARK 10 L.E.D. Beacon, available in AMBER colour also commonly known as Yellow and Orange, feature our latest micro optic reflector design housed internally offering a proper 360 degree high intensity light with a larger profile size for greater visibility. With superior daytime performance when comparing to other beacons, the SPARK Series beacons feature 100% solid state design with no moving parts or globe replacements required. Users can easily select flashing, rotating or combination patterns at different speed levels for each unique application.

Technical Specifications

  • SAE J845 Class 1
  • ECE R65 Class 2
  • MAX 5A @ 12VDC
  • 10 Long Life Colour Rich L.E.D.s
  • Superior Day Time Clarity & Performance
  • Visibly Larger Illuminated Signal Profile
  • 10-30VDC Multi Voltage Suitable
  • User Selectable Flashing & Rotating Patterns
  • Exclusive Micro Reflector Optics Design
  • UV Stabilised PC Lens
  • IP67 Weather Resistant
  • 100% Solid State Technology
  • No Replacement Globes or Gears Required
  • 3 Bolt Fixed Mount
  • Dimensions 80(Height) x 165 Base & 130 Lens(Diameter) mm

Wiring Diagram

  • Black = Ground Negative
  • Red = +10-30V Positive On/Off
  • Yellow = Pattern Select on Momentary Red
