AEGIS 4 Way Multi-Function Switch Panel Universal Controller

The entry level AEGIS 4 Way Switch Panel is a universal controller designed for customers who operate a vehicle that only requires a single switch for all warning lights, and three independent switches for Front, Left & Right side work lights. Perfect for security patrol vehicles that operate a full size patrol spec light bar, the AEGIS 4 Way controller is small and compact in size, with easy to identify L.E.D. back-lighting for each switch which are also color coded for convenient night time operations. The entry model AEGIS 4 Way switch box will be the standard controller for all our projects and light bars moving forward.

***Please note that customers can upgrade an AEGIS 4 Way Switch Panel Controller to the full fledged AEGIS 8 Way by simply purchasing the remote head only as the AEGIS Control System is fully backward and forward compatible sharing the same relay box***

Technical Specifications

• 4 Independent On/Off Universal Switches
• 10-30VDC Multi Voltage Suitable for Cars, Trucks & Bikes
• Covert Stealth BLACK Front Fascia Decal
• High Load Capacity
  • 3 x 15 Amp Switches
  • 1 x 20 Amp Switches
• Detachable Fuse Panel Cover for Easy Fuse Change
• Night Time Keypad Back-light Illumination with PARK Wire
• Standby Mode with IGNITION Wire for Rapid Activation
• CANCEL Function to OFF all ON Switches
• 4 Meter Wire Lead from Touch Pad to Switch Box with a RJ11 Connection

Standard Switches:

1. AEGIS (Level 3) @ 20A
   1. Can be used for all Warning Lights
2. LEFT @ 15A
   1. Can be used for Left Alley Work Light or Directional Arrow products
3. FRONT @ 15A
   1. Can be used for Front Take Down Lights or any other function
4. RIGHT @ 15A
   1. Can be used for Right Alley Work Light or Directional Arrow products
5. CANCEL
   1. Cancels all Activated Functions Immediately

AEGIS Product Dimensions:

• Control Remote Head: 90(L) x 50(W) x 14(H)mm
• Relay Control Box: 165(L) x 130(W) x 35(H)mm
